Komatsu 901XC-7
Stability regardless of the terrain
Komatsu 901XC-7
An agile thinning harvester for anyone harvesting in steep and difficult terrain. The eight-wheel design ensures an especially stable harvester that also leaves less of a mark thanks to its low ground pressure.
- 8WD design for high stability and great manoeuvrability in difficult terrain
- 200H crane with 10 / 11 m reach
- Choose from our range of options to customise your machine and make your working day even more comfortable and productive
Power
190kW@1850rpm
EU Stage V, Tier 4F
Gross lifting torque
197 kNm
145,300 lbf-ft
Max tractive effort
189 kN
42,487 lbf
Weight
From 20 710 kg
45,658 lb
Specifications
901XC-7
Overview
Dimensions
A. Width
With 600/45x24,5 tyres: 2 776 mm (9'1").
B. Length, total
7 705 mm (25'2")
C. Length, front axle to middle joint
1 850 mm (6'1")
D. Length, middle joint to rear axle
2 100 mm (6'11")
E. Transport height
24.5" Straight cab: 3820–3880 mm (depending on options). Transport position (cab max rear tilt, crane forward, light ramp tilted): 3810 mm
F. Ground clearance at steering joint
650 mm (12'6")
Note
Stated dimensions are nominal and may vary slightly depending on production tolerances and choice of equipment.
Weight
Approximate weight
From 20 710 kg (45,658 lb)
Engine
Type
AGCO Power 75FSTN-D5, 6-cylinder diesel engine with turbo and intercooler
Stroke volume
7.5 l (1.98 gal)
Power
190kW@1850 rpm (EU Stage V, Tier 4F)
Torque
1130 Nm @ 1500 rpm
Fuel tank
415 l (102 gal)
Boom
Model and reach
200H : 10 m (32'10")/ 11 m (36'1")
Gross lifting torque
198 kNm (146,037 lbf-ft)
Gross slewing torque
43 kNm (31,715 lbf-ft)
Heads
Available heads
S82, S92, C93, C124
Hydraulic system
Flow
367.5 l/min @ 1470 rpm
System pressure
280 bar
Electrical system
Voltage
24 V
Battery capacity
2 x 185 Ah
Generator
200 A
Transmission
Driving speed
0-25 km/h (0-15.6 mph)
Tractive force
189 kN (42,487 lbf)
Notes
General information
The specifications describe possible equipment, not which equipment is standard or optional. Standard and optional equipment varies between countries. Your sales representative has an up-to-date list of what is included. Weights are based on the equipment specified in the basic specification. Specifications and designs are subject to alteration without prior notice.
